Phoenix Contact · Power Supplies & UPS
QUINT4-PS/1AC/24DC/10 Power Supply 24 V DC / 10 A
Part number 2904601
4th-generation QUINT POWER DIN-rail supply, 24 V DC / 10 A, with SFB technology, power boost and preventive function monitoring.
- CE
- UL
- cULus
- RoHS
- ATEX
- EAC
Overview
QUINT POWER is the reference for control cabinets where availability matters. Selective Fuse Breaking (SFB) delivers up to six times nominal current for 15 ms so a standard miniature circuit breaker on a faulted branch trips reliably while the rest of the 24 V system stays up. Static boost (125 %) and dynamic boost (200 %) start heavy loads without oversizing, and the signalling output warns before a failure. Order code 2904601 is the single-phase 24 V / 10 A model; configure thresholds via NFC and the QUINT POWER app.
Key features
- SFB technology: 6 × nominal current for 15 ms trips standard breakers
- Static boost 12.5 A continuous, dynamic boost 20 A for 5 s
- Preventive function monitoring with signalling contact and NFC configuration
- Input 100–240 V AC wide range, efficiency up to 94.8 %
- -25…+70 °C operation, push-in terminals, ATEX Zone 2
Typical applications
- Control cabinet 24 V supply
- PLC and remote I/O power
- Sensor and actuator power
- Redundant supplies with QUINT ORING
Technical specifications — 2904601
| Output | |
|---|---|
| Output voltage | 24 V DC, adjustable 18–29.5 V |
| Output current | 10 A (12.5 A static boost, 20 A dynamic boost) |
| Input | |
| Input voltage | 100–240 V AC (85–264 V AC), 110–250 V DC |
| General | |
| Efficiency | up to 94.8 % |
| Width | 60 mm |
| MTBF | > 1,600,000 h (IEC 61709) |
| Environment | |
| Operating temperature | -25…+70 °C (derating above 60 °C) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
2904600 | QUINT4-PS/1AC/24DC/5 — 5 A version | Quote |
2904602 | QUINT4-PS/1AC/24DC/20 — 20 A version | Quote |
2866763 | QUINT-PS/1AC/24DC/10 — previous generation (3rd gen) | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Phoenix Contact product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8504.40 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the 2904601 available from stock, and what is the lead time?
Availability of the QUINT4-PS/1AC/24DC/10 Power Supply 24 V DC / 10 A changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 2904601 genuine, and what documentation comes with it?
We supply only genuine Phoenix Contact products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 2904601 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 2904601 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
