Axioline F PROFINET Bus Coupler AXL F BK PN
Part number 2701815
PROFINET RT/IRT bus coupler for Axioline F I/O, conformance class C, integrated 2-port switch, up to 63 modules per station.
- CE
- UL
- cULus
- RoHS
- REACH
- EAC
Overview
The AXL F BK PN connects Axioline F I/O modules to PROFINET with conformance class C support (IRT) and an integrated two-port switch for line topologies. Axioline F modules communicate over a local bus with cycle times in the microsecond range and plug together without tools, which suits fast machine I/O and skid-mounted process stations. Up to 63 modules can be attached to one coupler; power is fed through the coupler's push-in terminals.
Key features
- PROFINET RT/IRT, conformance class C, MRP
- Integrated 2-port switch for line topology
- Up to 63 Axioline F modules per station
- Local bus cycle in the microsecond range, IP20
- Push-in connection, no tools, device replacement without configuration
Typical applications
- Distributed machine I/O
- PROFINET line topologies
- Retrofit of Interbus stations
- Skid and process I/O
Technical specifications — 2701815
| Network | |
|---|---|
| Protocol | PROFINET RT/IRT (CC-C) |
| Ports | 2 × RJ45, integrated switch |
| I/O | |
| Local bus | up to 63 Axioline F modules |
| Power | |
| Supply voltage | 24 V DC |
| Environment | |
| Operating temperature | -25…+60 °C |
| Mounting | DIN rail, IP20 |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
2688459 | AXL F BK ETH — Modbus TCP bus coupler | Quote |
2701845 | AXL F BK EIP — EtherNet/IP bus coupler | Quote |
2688899 | AXL F BK EC — EtherCAT bus coupler | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
