PFC200 Controller 750-8210
Part number 750-8210
PFC200 G2 controller for the WAGO 750 I/O System: CODESYS V3, Linux, 2 × Gigabit Ethernet, MQTT, OPC UA, VPN and firewall.
- CE
- UL
- RoHS
Overview
The PFC200 750-8210 is both a PLC and an edge gateway. It runs CODESYS V3 for IEC 61131-3 logic and a hardened Linux underneath for Docker containers, MQTT publishing to cloud brokers, OPC UA, BACnet/IP and telecontrol protocols (IEC 60870-5-104, DNP3). Two Gigabit Ethernet interfaces, built-in VPN and firewall and an SD card make it a popular RTU for water and energy telemetry. Any module of the 750 I/O System can be plugged behind it — digital, analog, temperature, serial, counters.
Key features
- CODESYS V3 / IEC 61131-3 plus Linux with Docker support
- MQTT, OPC UA, BACnet/IP, Modbus TCP/RTU, IEC 60870-5-104, DNP3
- 2 × 10/100/1000 Ethernet (switch or separate), 1 × RS-232/485, USB
- Built-in OpenVPN/IPsec, firewall, TLS, WAGO Cloud connectivity
- Up to 64 I/O modules (250 with extensions), -20…+60 °C
Typical applications
- IIoT edge gateway
- Telemetry / RTU for water and energy
- Data logging and MQTT publishing
- Building automation (BACnet)
Technical specifications — 750-8210
| Processor | |
|---|---|
| CPU | ARM Cortex-A8, 1 GHz |
| Memory | 512 MB RAM, 4 GB flash |
| Communication | |
| Ethernet | 2 × 10/100/1000 Mbit/s |
| Serial | 1 × RS-232/485 |
| Protocols | |
| IT / IIoT | MQTT, OPC UA, Docker containers |
| OT | Modbus, BACnet/IP, IEC 60870-5-104, DNP3, CANopen (variants) |
| Power | |
| Supply voltage | 24 V DC |
| Environment | |
| Operating temperature | -20…+60 °C (750-8210/025-000: extended) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
750-8212 | PFC200 with 2 × ETH + RS-232/485 + CAN | Quote |
750-8202 | PFC200 G1 — previous generation | Quote |
750-362 | Modbus TCP fieldbus coupler — when no local logic is needed | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine WAGO product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the 750-8210 available from stock, and what is the lead time?
Availability of the PFC200 Controller 750-8210 changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 750-8210 genuine, and what documentation comes with it?
We supply only genuine WAGO products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 750-8210 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 750-8210 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
