Endress+Hauser · Level Measurement
Micropilot FMR60B Radar Level Transmitter
Part number FMR60B
80 GHz non-contact radar level transmitter for liquids, ±1 mm accuracy, 3° beam, Bluetooth commissioning, Heartbeat Technology, SIL2/3.
- CE
- ATEX
- IECEx
- SIL2
- RoHS
Overview
The Micropilot FMR60B is the current 80 GHz free-space radar for liquid level in storage and process tanks. The narrow 3° beam passes through small nozzles and ignores agitators, heating coils and build-up on the wall; the high dynamic range handles foam and condensation. Commissioning is done from a phone with Bluetooth and the SmartBlue app, and Heartbeat Technology verifies the instrument without emptying the tank. FMR60B is an ordering family — antenna, process connection, output and approvals are set in the full code.
Key features
- 80 GHz radar, 3° beam angle, measuring range up to 50 m
- Accuracy ±1 mm, independent of density, temperature and pressure
- Bluetooth and SmartBlue app commissioning; HART 7, PROFINET-APL option
- Heartbeat Technology diagnostics and verification
- SIL2 (SIL3 redundant), ATEX/IECEx; drip-off PTFE antenna for hygienic duty
Typical applications
- Storage tank level
- Process vessels with agitators
- Inventory management
- Water and wastewater basins
Technical specifications — FMR60B
| Measurement | |
|---|---|
| Frequency | 80 GHz (W-band) |
| Accuracy | ±1 mm |
| Range | up to 50 m |
| Beam angle | 3° |
| Process | |
| Process temperature | -40…+200 °C |
| Process pressure | -1…+20 bar |
| Antenna | PTFE drip-off, 40/50/80 mm |
| Output | |
| Signal | 4–20 mA HART 7, Bluetooth; PROFINET-APL option |
| Safety | |
| Functional safety | SIL2 / SIL3 |
| Environment | |
| Enclosure | IP66/68 |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
FMR62B | Micropilot FMR62B — flush-mounted PTFE-clad antenna for aggressive media | Quote |
FMR66B | Micropilot FMR66B — 80 GHz radar for bulk solids | Quote |
FMP51 | Levelflex FMP51 — guided-wave alternative for narrow nozzles | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Endress+Hauser product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 9026.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the FMR60B available from stock, and what is the lead time?
Availability of the Micropilot FMR60B Radar Level Transmitter changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the FMR60B genuine, and what documentation comes with it?
We supply only genuine Endress+Hauser products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the FMR60B outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the FMR60B is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
