MELSEC iQ-F FX5U-32MR/ES PLC
Part number FX5U-32MR/ES
Compact PLC with 16 inputs / 16 relay outputs, built-in Ethernet, RS-485, analog I/O and 4-axis positioning.
- CE
- UL
- RoHS
- EAC
Overview
The FX5U is the successor to the FX3U and is the default compact PLC in Japanese-invested factories across Vietnam. The 32MR/ES model runs on 100–240 V AC with relay outputs, which suits valve and contactor loads; pick FX5U-32MT/ES for transistor outputs when you need pulse-train positioning. Ethernet, RS-485 (MODBUS RTU / inverter communication), two analog inputs and one analog output are built in, so most small machines need no expansion modules. Programming is in GX Works3 with structured ladder and ST.
Key features
- Built-in Ethernet (100 Mbit/s), RS-485 and SD card slot
- 2 × analog inputs (0–10 V), 1 × analog output built in
- Up to 4-axis positioning via pulse outputs (transistor version) or simple-motion modules
- Processing speed 34 ns per basic instruction, 64k steps program memory
- Expandable up to 256 I/O points with FX5 extension modules; FX3 modules supported via bus conversion
Typical applications
- Standalone machinery
- Positioning and indexing
- Small-system automation
- Inverter control via RS-485
Technical specifications — FX5U-32MR/ES
| General | |
|---|---|
| Model | FX5U-32MR/ES |
| I/O points | 32 (16 DI / 16 DO) |
| Program memory | 64k steps |
| Instruction speed | 34 ns (LD) |
| I/O | |
| Inputs | 16 × 24 V DC sink/source |
| Outputs | 16 × relay, 2 A |
| Analog | 2 AI (0–10 V), 1 AO (0–10 V), 12-bit |
| Communication | |
| Ethernet | 1 × RJ45, 100BASE-TX, MODBUS/TCP, SLMP |
| Serial | 1 × RS-485 built in (MODBUS RTU, inverter protocol) |
| Power | |
| Supply voltage | 100–240 V AC |
| Service supply | 24 V DC, 400 mA |
| Environment | |
| Operating temperature | -20…+55 °C |
| Protection | IP20 |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
FX5U-32MT/ES | Transistor (sink) outputs — required for pulse-train positioning | Quote |
FX5U-32MT/ESS | Transistor (source) outputs | Quote |
FX5U-64MR/ES | 64 I/O version in the same family | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Mitsubishi Electric product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Can the FX5U-32MR/ES replace an FX3U-32MR/ES?
Functionally yes, and GX Works3 converts FX3U projects. Check the terminal layout, the 24 V service supply current and any FX3U special modules — some need the FX5-CNV-BUS adapter. We confirm compatibility before quoting.
Is the FX5U-32MR/ES available from stock, and what is the lead time?
Availability of the MELSEC iQ-F FX5U-32MR/ES PLC changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the FX5U-32MR/ES genuine, and what documentation comes with it?
We supply only genuine Mitsubishi Electric products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the FX5U-32MR/ES outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the FX5U-32MR/ES is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
