Schneider Electric · PLC & Controllers
Modicon M221 TM221CE16R Controller
Part number TM221CE16R
Compact PLC with 9 inputs, 7 relay outputs, 2 analog inputs, Ethernet and serial line, 100–240 V AC supply.
- CE
- UL
- RoHS
Overview
The Modicon M221 is Schneider Electric's entry-level machine controller, programmed free of charge in EcoStruxure Machine Expert – Basic. The TM221CE16R has Ethernet (Modbus TCP, EtherNet/IP adapter) and a serial line (Modbus RTU) on board, relay outputs and a wide-range AC supply, which makes it a frequent choice for simple packaging machines, pump panels and HVAC equipment. Expansion with TM3 modules adds up to 7 modules of digital, analog and temperature I/O.
Key features
- 9 DI (24 V DC), 7 relay outputs, 2 × 0–10 V analog inputs
- Ethernet (Modbus TCP, EtherNet/IP) + serial line (Modbus RTU)
- Removable screw terminal blocks, SD card slot, USB mini-B programming port
- Up to 7 TM3 expansion modules, 2 cartridge slots
- Free EcoStruxure Machine Expert – Basic software
Typical applications
- Compact machines
- Pump and HVAC panels
- Standalone control
- OEM equipment
Technical specifications — TM221CE16R
| I/O | |
|---|---|
| Digital I/O | 9 DI / 7 DO (relay, 2 A) |
| Analog inputs | 2 × 0–10 V, 10-bit |
| High-speed counters | 4 × 100 kHz |
| Communication | |
| Ethernet | 1 × RJ45, Modbus TCP, EtherNet/IP |
| Serial | 1 × RS-232/RS-485, Modbus RTU |
| Power | |
| Supply voltage | 100–240 V AC |
| Environment | |
| Operating temperature | -10…+55 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
TM221CE16T | Transistor outputs, 24 V DC supply | Quote |
TM221CE24R | 24 I/O version (14 DI / 10 DO relay) | Quote |
TM221C16R | Same without Ethernet | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Schneider Electric product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the TM221CE16R available from stock, and what is the lead time?
Availability of the Modicon M221 TM221CE16R Controller changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the TM221CE16R genuine, and what documentation comes with it?
We supply only genuine Schneider Electric products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the TM221CE16R outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the TM221CE16R is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
