Schneider Electric · Variable Frequency Drives
Altivar Machine ATV320 1.5 kW
Part number ATV320U15N4C
Compact machine drive, 1.5 kW, 3-phase 380–500 V, with STO (SIL2/PLd), Modbus and CANopen on board.
- CE
- UL
- RoHS
- SIL2
Overview
The Altivar Machine ATV320 is built for OEM machine builders: compact or book format, integrated safety (STO, SIL2/PL d), and Modbus RTU and CANopen built in, with Ethernet available through option cards. The ATV320U15N4C is the 1.5 kW compact-format model for 400 V three-phase supply. Sensorless flux vector control gives good torque at low speed for conveyors, mixers and material-handling axes.
Key features
- 1.5 kW, 3-phase 380–500 V input, compact format
- Safe Torque Off (SIL2 / PL d) integrated
- Modbus RTU and CANopen on board; EtherNet/IP, PROFINET, EtherCAT via option
- Sensorless flux vector control, up to 170 % starting torque
- Configured with SoMove or the remote graphic display
Typical applications
- Packaging machines
- Conveyors and material handling
- Textile and printing machinery
- Mixers and pumps on OEM equipment
Technical specifications — ATV320U15N4C
| Power | |
|---|---|
| Rated power | 1.5 kW |
| Supply voltage | 3-phase 380–500 V |
| Output current | 4.1 A |
| Safety | |
| Safety function | STO, SIL2 / PL d |
| Communication | |
| On board | Modbus RTU, CANopen |
| Optional | EtherNet/IP, Modbus TCP, PROFINET, EtherCAT, PROFIBUS DP |
| Environment | |
| Enclosure | IP20 |
| Operating temperature | -10…+50 °C (60 °C with derating) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
ATV320U15N4B | Book-format version of the same rating | Quote |
ATV340U15N4 | Altivar Machine ATV340 — higher performance, Ethernet on board | Quote |
ATV320U22N4C | 2.2 kW — next size up | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Schneider Electric product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8504.40 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the ATV320U15N4C available from stock, and what is the lead time?
Availability of the Altivar Machine ATV320 1.5 kW changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the ATV320U15N4C genuine, and what documentation comes with it?
We supply only genuine Schneider Electric products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the ATV320U15N4C outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the ATV320U15N4C is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
