Preventa XPSU Safety Relay Module
Part number XPSUAF13AP
Universal safety relay for e-stop and guard monitoring up to Cat. 4 / PL e / SIL 3, 3 NO safety contacts + 1 NC, 24 V AC/DC to 240 V AC supply.
- CE
- UL
- cULus
- SIL3
- RoHS
- REACH
- EAC
Overview
The Preventa XPSUAF13AP is the replacement for the XPSAF5130 and covers the most common safety circuits — emergency stop, guard switches, safety mats and light-curtain OSSD outputs — in one 22.5 mm module. Its universal supply voltage (24 V AC/DC to 240 V AC) lets you stock one part number across machines with different control voltages, and the start mode (automatic, manual, monitored) is selected by wiring.
Key features
- Category 4, PL e (ISO 13849-1), SIL 3 (IEC 62061)
- Universal supply 24 V AC/DC … 240 V AC
- 3 NO safety outputs (6 A) + 1 NC signalling output
- Single- or dual-channel input, automatic or monitored manual start
- 22.5 mm housing, screw or spring terminals
Typical applications
- Emergency-stop monitoring
- Safety guard/door monitoring
- Safety mat and light curtain evaluation
- Press control
Technical specifications — XPSUAF13AP
| Safety | |
|---|---|
| Safety level | Cat. 4 / PL e / SIL 3 |
| Function | E-stop, guard, light curtain, mat — 1 or 2 channel |
| Electrical | |
| Supply voltage | 24 V AC/DC … 240 V AC |
| Safety contacts | 3 NO, 6 A max. |
| Auxiliary contact | 1 NC |
| Mechanical | |
| Width | 22.5 mm, DIN rail |
| Environment | |
| Operating temperature | -25…+55 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
XPSUAF13AC | Same module with spring terminals | Quote |
XPSAF5130 | Predecessor — replaced by XPSUAF13AP | Quote |
XPSUAT13A3AP | Preventa XPSUAT — adds time-delayed contacts | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Schneider Electric product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8536.49 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the XPSUAF13AP available from stock, and what is the lead time?
Availability of the Preventa XPSU Safety Relay Module changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the XPSUAF13AP genuine, and what documentation comes with it?
We supply only genuine Schneider Electric products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the XPSUAF13AP outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the XPSUAF13AP is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
