SICK · Safety Relays & Controllers
deTec4 Core Safety Light Curtain
Part number C4C-SA18030A10000
Type 4 safety light curtain, 300 mm protective height, 14 mm resolution (finger protection), sender unit of the deTec4 Core series.
- CE
- UL
- SIL3
- IP67
- RoHS
Overview
The deTec4 Core is SICK's Type 4 (IEC 61496) safety light curtain for hazardous-point and access guarding. The C4C-SA18030A10000 is the sender with 300 mm protective height and 14 mm resolution for finger protection; it is paired with the matching receiver C4C-EA18030A10000. Integrated alignment aid and status LEDs make commissioning straightforward, and the slim housing fits where older curtains would not. No configuration software is needed — functions are set by wiring.
Key features
- Type 4 per IEC 61496-1/-2, SIL3 (IEC 61508), PL e (ISO 13849-1)
- 14 mm resolution, 300 mm protective height, scanning range up to 10 m
- Integrated alignment aid, no software configuration
- Automatic or manual restart via wiring, EDM (external device monitoring)
- IP65 / IP67 aluminium housing, M12 connection
Typical applications
- Finger and hand protection at hazardous points
- Access guarding on cells and machines
- Press and punching safety
Technical specifications — C4C-SA18030A10000
| Safety | |
|---|---|
| Type | Type 4 (IEC 61496) |
| Safety level | SIL3 / PL e / Category 4 |
| Detection | |
| Resolution | 14 mm |
| Protective height | 300 mm |
| Scanning range | 0.1…10 m |
| Response time | ≤ 13 ms |
| Electrical | |
| Supply voltage | 24 V DC ± 20 % |
| Connection | M12, 5-pin (sender), 8-pin (receiver) |
| Environment | |
| Protection | IP65 / IP67 |
| Operating temperature | -30…+55 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
C4C-EA18030A10000 | Matching receiver — order together with the sender | Quote |
C4C-SA18030A10000 + C4C-EA18030A10000 | Complete set (sender + receiver) | Quote |
C4C-SA30030A10000 | 30 mm resolution (hand protection), 300 mm height | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine SICK product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8536.50 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Do I need a safety relay with the deTec4 Core?
The receiver's OSSD outputs must switch the machine's hazardous movement through a safety relay or safety PLC with external device monitoring. A Schneider XPSUAF13AP or Omron G9SE-401 relay is a typical pairing; we can supply the complete circuit.
Is the C4C-SA18030A10000 available from stock, and what is the lead time?
Availability of the deTec4 Core Safety Light Curtain changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the C4C-SA18030A10000 genuine, and what documentation comes with it?
We supply only genuine SICK products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the C4C-SA18030A10000 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the C4C-SA18030A10000 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
