ABB · Variable Frequency Drives
ACS580 General-Purpose Drive 5.5 kW
Part number ACS580-01-12A6-4
Wall-mounted AC drive, 5.5 kW / 12.6 A, 3-phase 380–480 V, IP21, with built-in EMC filter, brake chopper and Modbus RTU.
- CE
- UL
- cULus
- RoHS
- EAC
Overview
The ACS580 is ABB's general-purpose drive for pumps, fans, conveyors and compressors — the applications that make up most of a plant's motor load. The -12A6-4 frame is rated 5.5 kW normal duty (4 kW heavy duty) at 400 V. It ships with an assistant control panel that walks through commissioning, an integrated C2 EMC filter and brake chopper, and Modbus RTU on board; fieldbus adapters add PROFINET, EtherNet/IP or PROFIBUS. Coated circuit boards are standard, which matters in Vietnam's humid plant rooms.
Key features
- 5.5 kW normal duty / 4 kW heavy duty, 12.6 A output at 400 V
- Scalar and vector control, energy optimizer, pump and fan macros
- Integrated EMC filter (category C2), brake chopper, Modbus RTU
- Assistant control panel with commissioning wizard and backup
- Coated boards; IP21 standard, IP55 variant available
Typical applications
- Pumps
- Fans and blowers
- Conveyors
- Compressors and mixers
Technical specifications — ACS580-01-12A6-4
| Power | |
|---|---|
| Rated power (ND/HD) | 5.5 kW / 4 kW |
| Output current (ND) | 12.6 A |
| Supply voltage | 3-phase 380–480 V, 50/60 Hz |
| Frame size | R1 |
| Control | |
| Control modes | Scalar (V/f), vector |
| Built-in | EMC filter C2, brake chopper, STO (SIL3) |
| Communication | |
| On board | Modbus RTU (EIA-485) |
| Optional | PROFINET, EtherNet/IP, PROFIBUS DP via FENA/FPBA adapters |
| Environment | |
| Enclosure | IP21 (IP55 option) |
| Operating temperature | -15…+50 °C (derating above 40 °C) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
ACS580-01-017A-4 | 7.5 kW — next size up | Quote |
ACS480-04-12A7-4 | ACS480 — compact machinery drive, same power | Quote |
ACS880-01-12A6-3 | ACS880 — industrial drive with DTC for demanding duty | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine ABB product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8504.40 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the ACS580-01-12A6-4 available from stock, and what is the lead time?
Availability of the ACS580 General-Purpose Drive 5.5 kW changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the ACS580-01-12A6-4 genuine, and what documentation comes with it?
We supply only genuine ABB products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the ACS580-01-12A6-4 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the ACS580-01-12A6-4 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
