Rockwell Automation · Variable Frequency Drives
PowerFlex 525 AC Drive 4 kW
Part number 25B-D010N104
Compact VFD, 4 kW / 5 HP, 380–480 V 3-phase, embedded EtherNet/IP, Safe Torque Off, V/Hz, SVC and closed-loop vector control.
- CE
- UL
- cULus
- RoHS
- REACH
- EAC
Overview
The PowerFlex 525 is the standard machine drive in Allen-Bradley architectures. The 25B-D010N104 delivers 4 kW (5 HP) at 480 V with embedded EtherNet/IP, Safe Torque Off and a removable control module, so panels can be wired and configured before the power module is installed. It supports V/Hz, sensorless vector and closed-loop vector control with an encoder card, and is configured through Connected Components Workbench or directly from Studio 5000 via the Add-On Profile.
Key features
- 4 kW / 5 HP at 380–480 V, 10.5 A normal duty
- Embedded EtherNet/IP (dual-port option), USB configuration
- Safe Torque Off (SIL2 / PL d) standard
- Removable MainsFree control module
- V/Hz, SVC, closed-loop vector and permanent-magnet motor control
Typical applications
- Conveyors
- Pumps and fans
- Mixers
- Machine spindles and positioning
Technical specifications — 25B-D010N104
| Ratings | |
|---|---|
| Power | 4 kW / 5 HP |
| Input voltage | 380–480 V AC, 3-phase |
| Output current (ND) | 10.5 A |
| Frame | B |
| Control | |
| Motor control | V/Hz, SVC, closed-loop velocity, PM motor |
| Communication | |
| Network | EtherNet/IP embedded; DeviceNet, PROFIBUS via option card |
| Safety | |
| Functional safety | STO, SIL2 / PL d |
| Environment | |
| Operating temperature | -20…+50 °C (60 °C derated) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
25B-D013N104 | 5.5 kW / 7.5 HP | Quote |
25A-D010N104 | PowerFlex 523 — same frame without Ethernet and STO | Quote |
25C-D010N104 | PowerFlex 527 — integrated motion with CompactLogix | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Rockwell Automation product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8504.40 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the 25B-D010N104 available from stock, and what is the lead time?
Availability of the PowerFlex 525 AC Drive 4 kW changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 25B-D010N104 genuine, and what documentation comes with it?
We supply only genuine Rockwell Automation products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 25B-D010N104 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 25B-D010N104 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
