Rockwell Automation · HMI & Operator Panels
PanelView 800 7" HMI Terminal
Part number 2711R-T7T
7-inch colour touch HMI for Micro800 and CompactLogix, EtherNet/IP and serial, configured in Connected Components Workbench.
- CE
- UL
- cULus
- RoHS
Overview
The PanelView 800 is the natural HMI for Micro800 and CompactLogix controllers: it is configured in the same Connected Components Workbench software, speaks EtherNet/IP natively and includes alarms, recipes, trends and data logging to microSD. The 2711R-T7T is the 7-inch model, the most common size on OEM machines exported to North American plants.
Key features
- 7-inch TFT touch, 800 × 480, 65K colours
- EtherNet/IP, Modbus TCP, RS-232/422/485 serial, USB and microSD
- Alarms, recipes, trending and data logging built in
- Configured in Connected Components Workbench (free)
- Also connects to MicroLogix and third-party Modbus devices
Typical applications
- Machine HMI for Micro800
- CompactLogix cell visualization
- OEM machines for North America
Technical specifications — 2711R-T7T
| Display | |
|---|---|
| Screen size | 7-inch TFT touch |
| Resolution | 800 × 480 |
| Communication | |
| Ethernet | 1 × 10/100, EtherNet/IP and Modbus TCP |
| Serial | RS-232/422/485 |
| Power | |
| Supply voltage | 24 V DC |
| Environment | |
| Front protection | IP65 |
| Operating temperature | 0…+55 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
2711R-T10T | 10-inch version | Quote |
2711R-T4T | 4-inch version | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Rockwell Automation product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the 2711R-T7T available from stock, and what is the lead time?
Availability of the PanelView 800 7" HMI Terminal changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 2711R-T7T genuine, and what documentation comes with it?
We supply only genuine Rockwell Automation products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 2711R-T7T outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 2711R-T7T is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
