Siemens · HMI & Operator Panels
SIMATIC HMI KTP700 Basic Panel
Part number 6AV2123-2GB03-0AX0
7-inch widescreen touch panel, 800 × 480, PROFINET, 8 function keys, configured in WinCC Basic (TIA Portal).
- CE
- UL
- cULus
- RoHS
- REACH
Overview
The KTP700 Basic PN is the standard operator panel for S7-1200 machines: 7-inch TFT, 64K colours, analog-resistive touch plus eight freely configurable function keys, and a PROFINET port that connects directly to the CPU. It is configured in WinCC Basic, included with STEP 7 Basic, and supports recipes, alarms, trends, user administration and a USB port for data export. For PROFIBUS or MPI controllers choose the KTP700 Basic DP (6AV2123-2GA03-0AX0); for S7-1500 projects that need scripts or more archives, step up to the KTP700 Comfort.
Key features
- 7-inch TFT widescreen, 800 × 480 pixels, 64K colours, dimmable LED backlight
- Analog-resistive touch screen + 8 tactile function keys
- PROFINET interface (RJ45); also connects to S7-300/400, S7-1500 and third-party PLCs via Ethernet
- Recipes, alarms, trends, 10 languages online, USB port for data and backup
- Configured in WinCC Basic within TIA Portal (V13 SP1 or later)
Typical applications
- Machine operator interface
- Recipe and status display
- Line and skid HMI
- Replacement for KTP600 Basic
Technical specifications — 6AV2123-2GB03-0AX0
| Display | |
|---|---|
| Size | 7-inch TFT widescreen |
| Resolution | 800 × 480 pixels |
| Colours | 64K |
| Touch | Analog-resistive, single touch |
| Operation | |
| Function keys | 8, configurable, with LED |
| Memory | 10 MB user memory |
| Communication | |
| Interface | 1 × PROFINET RJ45 (10/100 Mbit/s) |
| Other | 1 × USB 2.0 host |
| Power | |
| Supply voltage | 24 V DC (19.2–28.8 V) |
| Environment | |
| Front protection | IP65 (rear IP20) |
| Operating temperature | 0…+50 °C |
| Cut-out (W × H) | 197 × 141 mm |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
6AV2123-2GA03-0AX0 | KTP700 Basic DP — PROFIBUS/MPI interface instead of PROFINET (not interchangeable) | Quote |
6AV2124-0GC01-0AX0 | KTP700 Comfort — scripts, more archives, PROFINET + PROFIBUS | Quote |
6AV2123-2JB03-0AX0 | KTP900 Basic — 9-inch version | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Siemens product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the KTP700 Basic touch screen capacitive?
No. The KTP700 Basic uses an analog-resistive touch screen, which works with gloves and in dusty environments. Capacitive multi-touch is available on the Unified Basic and Comfort Panel families.
Can the KTP700 Basic PN replace a KTP600 Basic PN?
Yes. Siemens kept the same 197 × 141 mm panel cut-out, so the KTP700 Basic PN is a mechanical drop-in for the KTP600 Basic PN, and the project migrates in TIA Portal. Make sure the old project is available in WinCC flexible 2008 SP3 or TIA format before you order.
Is the 6AV2123-2GB03-0AX0 available from stock, and what is the lead time?
Availability of the SIMATIC HMI KTP700 Basic Panel changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 6AV2123-2GB03-0AX0 genuine, and what documentation comes with it?
We supply only genuine Siemens products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 6AV2123-2GB03-0AX0 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 6AV2123-2GB03-0AX0 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
