SIMATIC S7-1200 CPU 1214C DC/DC/DC
Part number 6ES7214-1AG40-0XB0
Compact PLC with 14 DI / 10 DO / 2 AI on board, 100 KB work memory and integrated PROFINET.
- CE
- UL
- cULus
- RoHS
- REACH
- EAC
Overview
The CPU 1214C is the most common S7-1200 variant in Vietnamese machine building: enough on-board I/O for a typical packaging or conveyor machine, a PROFINET port for HMI and remote I/O, and six high-speed counters for encoders and flow meters. The DC/DC/DC version (24 V supply, 24 V inputs, transistor outputs) is the right choice for fast switching and PLC-to-PLC signal exchange; choose the AC/DC/Rly variant (6ES7214-1BG40-0XB0) when you need relay outputs or 230 V supply. Programmed in TIA Portal STEP 7 Basic or Professional, it expands with up to 8 signal modules, 3 communication modules and one signal board.
Key features
- Integrated PROFINET IO controller / I-device interface
- 14 × 24 V DC inputs, 10 × 24 V DC transistor outputs, 2 × 0–10 V analog inputs
- 100 KB work memory, 4 MB load memory, expandable via SIMATIC memory card
- Six high-speed counters up to 100 kHz, 4 PTO/PWM outputs for stepper control
- Web server, OPC UA server (firmware V4.4+), PID auto-tuning
Typical applications
- Machine control
- Packaging lines
- Conveyor sequencing
- Building and utility automation
Technical specifications — 6ES7214-1AG40-0XB0
| General | |
|---|---|
| CPU | 1214C DC/DC/DC |
| Work memory | 100 KB |
| Load memory | 4 MB integrated (expandable) |
| Bit operation time | 0.08 µs |
| I/O | |
| Digital inputs | 14 × 24 V DC (6 usable as HSC) |
| Digital outputs | 10 × 24 V DC, 0.5 A transistor |
| Analog inputs | 2 × 0–10 V, 10-bit |
| Expansion | 8 signal modules, 1 signal board, 3 communication modules |
| Communication | |
| Interface | 1 × PROFINET RJ45 (10/100 Mbit/s) |
| Protocols | PROFINET IO, S7, OPC UA, Modbus TCP (library), open user communication |
| Power | |
| Supply voltage | 20.4–28.8 V DC |
| Sensor supply | 24 V DC, 400 mA |
| Environment | |
| Operating temperature | -20…+60 °C horizontal, -20…+50 °C vertical |
| Protection | IP20 |
| Dimensions (W × H × D) | 110 × 100 × 75 mm |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
6ES7214-1BG40-0XB0 | AC/DC/Relay variant: 230 V AC supply, relay outputs | Quote |
6ES7214-1HG40-0XB0 | DC/DC/Relay variant: 24 V supply, relay outputs | Quote |
6ES7215-1AG40-0XB0 | CPU 1215C: 2 PROFINET ports, 2 AO, 125 KB — upgrade path | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Siemens product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the 6ES7214-1AG40-0XB0 a direct replacement for the older 6ES7214-1AG31-0XB0?
Yes. The -0XB0 firmware V4 CPU replaces the V3 (-1AG31) in the same footprint. Programs must be migrated in TIA Portal V13 or later; V3 projects open and compile with minor adjustments. We can check your project before you order.
Is the 6ES7214-1AG40-0XB0 available from stock, and what is the lead time?
Availability of the SIMATIC S7-1200 CPU 1214C DC/DC/DC changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 6ES7214-1AG40-0XB0 genuine, and what documentation comes with it?
We supply only genuine Siemens products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 6ES7214-1AG40-0XB0 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 6ES7214-1AG40-0XB0 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
