AC500 PM5630-2ETH CPU
Part number PM5630-2ETH
AC500 V3 processor module with two independent Ethernet ports, 8 MB program memory and CODESYS V3 engineering.
- CE
- UL
- RoHS
- EAC
Overview
The PM5630-2ETH is a mid-range AC500 V3 CPU for water, energy and infrastructure projects where the controller also acts as a communication hub. Two independent Ethernet interfaces let you separate the plant network from the SCADA or remote-access network. It is programmed in ABB Automation Builder (CODESYS V3) and supports the full AC500 I/O and communication-module range, including PROFINET, EtherCAT and Modbus TCP, plus IEC 60870-5-104 for telecontrol.
Key features
- 2 × independent Ethernet ports (10/100 Mbit/s)
- 8 MB user program memory, 4 MB data memory
- Automation Builder / CODESYS V3 with IEC 61131-3 languages
- Onboard display and diagnostic keypad
- Up to 10 I/O modules locally; PROFINET, EtherCAT, CANopen via communication modules
Typical applications
- Water and wastewater plant control
- Energy and substation automation
- Communication hub between networks
- Marine auxiliary systems
Technical specifications — PM5630-2ETH
| Processor | |
|---|---|
| Program memory | 8 MB |
| Data memory | 4 MB |
| Cycle time | 0.002 µs/instruction (bit) |
| Communication | |
| Ethernet | 2 × independent, 10/100 Mbit/s |
| Protocols | Modbus TCP, OPC UA, IEC 60870-5-104, PROFINET via CM |
| Engineering | |
| Software | ABB Automation Builder (CODESYS V3) |
| Power | |
| Supply voltage | 24 V DC |
| Environment | |
| Operating temperature | 0…+60 °C (XC version: -40…+70 °C) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
PM5650-2ETH | Higher performance AC500 V3 CPU, 16 MB | Quote |
PM5630-2ETH-XC | Extreme-conditions version: -40…+70 °C, conformal coating | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine ABB product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8537.10 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the PM5630-2ETH available from stock, and what is the lead time?
Availability of the AC500 PM5630-2ETH CPU changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the PM5630-2ETH genuine, and what documentation comes with it?
We supply only genuine ABB products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the PM5630-2ETH outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the PM5630-2ETH is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
