MGate MB3180 Modbus Gateway
Part number MGate MB3180
1-port Modbus TCP ↔ Modbus RTU/ASCII gateway, RS-232/422/485, 12–48 V DC, DIN rail, for bringing serial meters and instruments onto Ethernet.
- CE
- UL
- RoHS
Overview
The MGate MB3180 is the simplest way to put a serial Modbus device — a power meter, a flow computer, an old PLC — onto a Modbus TCP network. It converts transparently between Modbus TCP and RTU/ASCII, supports up to 31 serial slaves with automatic unit-ID routing, and accepts up to 16 TCP master connections. Configuration takes minutes through a web browser or the MGate Manager utility. Wide-temperature (-T) version available.
Key features
- Modbus TCP ↔ RTU/ASCII conversion, master or slave on either side
- 1 × RS-232/422/485 serial port, 1 × 10/100 Ethernet
- Up to 31 serial slaves, 16 simultaneous TCP masters
- Web console and Windows utility configuration, built-in traffic monitor
- 12–48 V DC, DIN rail; 5-year warranty
Typical applications
- Serial meter and instrument integration into SCADA
- Legacy PLC connection to modern HMIs
- Energy metering networks
- Substation device integration
Technical specifications — MGate MB3180
| Serial | |
|---|---|
| Ports | 1 × RS-232/422/485, DB9 |
| Network | |
| Ethernet | 1 × 10/100BaseT(X), RJ45 |
| Protocols | |
| Conversion | Modbus TCP ↔ Modbus RTU/ASCII |
| Connections | 16 TCP masters, 31 serial slaves |
| Power | |
| Supply voltage | 12–48 V DC |
| Environment | |
| Operating temperature | 0…+60 °C (-T: -40…+75 °C) |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
MGate MB3170 | Advanced 1-port gateway with redundant power and 2 Ethernet ports | Quote |
MGate MB3280 | 2-port serial version | Quote |
MGate MB3180-T | Wide-temperature version | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Moxa product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8517.62 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the MGate MB3180 available from stock, and what is the lead time?
Availability of the MGate MB3180 Modbus Gateway changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the MGate MB3180 genuine, and what documentation comes with it?
We supply only genuine Moxa products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the MGate MB3180 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the MGate MB3180 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
