UC-2112-LX Arm Edge Computer
Part number UC-2112-LX
Compact Arm-based edge computer with Moxa Industrial Linux, 2 × LAN, 2 × serial, microSD, fanless -40…+70 °C, for data acquisition and protocol conversion.
- CE
- UL
- RoHS
Overview
The UC-2112-LX is a palm-sized Linux computer for the edge of an IIoT network: it polls PLCs and meters over Modbus or OPC UA, buffers the data and publishes it to a broker or cloud over MQTT. Moxa Industrial Linux (Debian-based) comes with 10 years of security patches, which matters for devices that stay in the field for a decade. Two LAN ports let you separate the OT and IT networks, two serial ports connect legacy devices, and the fanless design runs from -40 to +70 °C.
Key features
- Arm Cortex-A8 1 GHz, 512 MB RAM, 8 GB eMMC, Moxa Industrial Linux
- 2 × 10/100 LAN, 2 × RS-232/422/485, microSD, USB
- 10-year Linux support with security patches, secure boot
- Fanless -40…+70 °C, 12–48 V DC, DIN rail or wall
- Optional Moxa ThingsPro Edge for Modbus-to-MQTT without coding
Typical applications
- Edge data acquisition
- Protocol conversion to MQTT / OPC UA
- IIoT gateway for remote sites
- Vessel and vehicle data logging
Technical specifications — UC-2112-LX
| Processor | |
|---|---|
| CPU | Arm Cortex-A8, 1 GHz |
| Memory | 512 MB DDR3, 8 GB eMMC |
| Interfaces | |
| LAN | 2 × 10/100 Mbit/s |
| Serial | 2 × RS-232/422/485 |
| Storage | microSD slot |
| Software | |
| OS | Moxa Industrial Linux (Debian), 10-year support |
| Power | |
| Supply voltage | 12–48 V DC |
| Environment | |
| Operating temperature | -40…+70 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
UC-2104-LX | 1 × LAN, 1 × serial — smaller version | Quote |
UC-8112A-ME-T-LX | Cellular-capable edge computer with mini-PCIe slot | Quote |
750-8210 | WAGO PFC200 — controller alternative with CODESYS and MQTT | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Moxa product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8471.50 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the UC-2112-LX available from stock, and what is the lead time?
Availability of the UC-2112-LX Arm Edge Computer changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the UC-2112-LX genuine, and what documentation comes with it?
We supply only genuine Moxa products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the UC-2112-LX outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the UC-2112-LX is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
