Pepperl+Fuchs · Industrial Sensors
UB800 Ultrasonic Sensor M18
Part number UB800-18GM40-E5-V1
Ultrasonic proximity sensor, 50–800 mm sensing range, independent of colour and transparency, PNP output, M18 housing, M12 connector.
- CE
- UL
- RoHS
- REACH
Overview
Ultrasonic sensors solve the detection tasks that defeat photoelectric sensors: clear films and bottles, liquids, dark absorbent surfaces and dusty environments. The UB800-18GM40-E5-V1 measures distance to 800 mm with a temperature-compensated transducer, teaches switch points by push button or teach wire, and comes in a compact M18 nickel-plated brass housing with an M12 connector.
Key features
- 50…800 mm sensing range, unaffected by colour or transparency
- Temperature-compensated for stable accuracy
- Push-button and wire teach of switch points, NO/NC programmable
- M18 metal housing, IP67, M12 4-pin connector
- Synchronization of multiple sensors to avoid crosstalk
Typical applications
- Clear-film and bottle detection
- Liquid level in small vessels
- Roll diameter monitoring
- Height verification
Technical specifications — UB800-18GM40-E5-V1
| Sensing | |
|---|---|
| Technology | Ultrasonic |
| Sensing range | 50…800 mm |
| Dead band | 0…50 mm |
| Repeat accuracy | ≤ 0.1 % of full scale |
| Electrical | |
| Output | PNP NO/NC, programmable |
| Supply voltage | 10…30 V DC |
| Mechanical | |
| Housing | M18 × 1, nickel-plated brass |
| Connection | M12, 4-pin |
| Environment | |
| Enclosure rating | IP67 |
| Operating temperature | -25…+70 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
UB500-18GM75-E5-V15 | 500 mm range version | Quote |
UB800-18GM40-I-V1 | Analog 4–20 mA output version | Quote |
UC2000-30GM70-IE2R2-V15 | M30, 2 m range, analog + switching | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Pepperl+Fuchs product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8536.50 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the UB800-18GM40-E5-V1 available from stock, and what is the lead time?
Availability of the UB800 Ultrasonic Sensor M18 changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the UB800-18GM40-E5-V1 genuine, and what documentation comes with it?
We supply only genuine Pepperl+Fuchs products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the UB800-18GM40-E5-V1 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the UB800-18GM40-E5-V1 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
