E2E Inductive Proximity Sensor M30
Part number E2E-X10D1-N
Shielded M30 inductive sensor, 10 mm sensing distance, DC 2-wire NO output, pre-wired, IP67 brass housing.
- CE
- RoHS
- IP67
Overview
The E2E is Omron's long-running general-purpose inductive sensor family and one of the most-ordered sensors in Vietnamese plants. The E2E-X10D1-N is a shielded M30 with 10 mm sensing distance and a DC 2-wire normally-open output — polarity-free wiring that connects to PLC inputs or relays without a separate supply line. Nickel-plated brass housing, IP67 and a 2 m pre-wired cable make it a drop-in for end-of-travel, presence and position detection.
Key features
- 10 mm sensing distance, shielded (flush-mountable)
- DC 2-wire, normally open, 12–24 V DC
- IP67 nickel-plated brass housing, M30 × 1.5
- Pre-wired 2 m cable (-M1 for M12 connector)
- Operation and power indicator LEDs
Typical applications
- Position detection
- End-of-travel and cylinder position
- Object presence on conveyors
- Metal part counting
Technical specifications — E2E-X10D1-N
| Sensing | |
|---|---|
| Sensing distance | 10 mm ± 10 % |
| Target | Ferrous metal (standard target 30 × 30 × 1 mm) |
| Output | DC 2-wire, NO |
| Switching frequency | 100 Hz |
| Electrical | |
| Supply voltage | 12–24 V DC (10–30 V DC) |
| Load current | 3–100 mA |
| Mechanical | |
| Housing | M30 × 1.5, nickel-plated brass |
| Connection | Pre-wired cable, 2 m |
| Environment | |
| Protection | IP67 |
| Operating temperature | -25…+70 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
E2E-X10D2-N | Normally-closed version | Quote |
E2E-X10MD1-N | Unshielded, 18 mm sensing distance | Quote |
E2E-X10D1-M1 | M12 connector version | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Omron product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 8536.50 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the E2E-X10D1-N available from stock, and what is the lead time?
Availability of the E2E Inductive Proximity Sensor M30 changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the E2E-X10D1-N genuine, and what documentation comes with it?
We supply only genuine Omron products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the E2E-X10D1-N outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the E2E-X10D1-N is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
