Sysmac NX1P2-9024DT Machine Controller
Part number NX1P2-9024DT
Compact machine controller with EtherCAT master, EtherNet/IP, 24 built-in I/O and up to 4 synchronized motion axes.
- CE
- UL
- RoHS
Overview
The NX1P2 brings the Sysmac platform — one software (Sysmac Studio) for logic, motion, safety and HMI — into a compact controller. The 9024DT model has 14 inputs and 10 transistor (PNP) outputs built in, an EtherCAT port for servo drives and remote I/O, and EtherNet/IP for HMI and plant connectivity. It handles up to 4 synchronized motion axes (8 with single-axis positioning) and is widely used on packaging and electronics assembly machines that pair with Omron 1S servo drives.
Key features
- EtherCAT master (up to 16 slaves) + EtherNet/IP built in
- Motion control: 4 synchronized axes, electronic cam and gear
- 14 DI / 10 DO (PNP) built in, up to 8 NX-series I/O units locally
- Option boards for serial (RS-232C/485) and analog I/O
- Sysmac Studio: IEC 61131-3, PLCopen motion function blocks
Typical applications
- Synchronized motion machines
- Packaging machines
- Electronics assembly and inspection
- High-precision control
Technical specifications — NX1P2-9024DT
| Control | |
|---|---|
| Program capacity | 1.5 MB |
| Motion axes | 4 synchronized (8 single-axis) |
| Instruction time | 3.3 ns (LD) |
| Communication | |
| Fieldbus | EtherCAT master, EtherNet/IP |
| Option | 2 option board slots: serial or analog |
| I/O | |
| Built-in I/O | 14 DI / 10 DO, PNP |
| Power | |
| Supply voltage | 24 V DC |
| Environment | |
| Operating temperature | 0…+55 °C |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
NX1P2-9024DT1 | NPN output version | Quote |
NX1P2-1140DT | 40 built-in I/O, 8 synchronized axes | Quote |
NX1P2-9B24DT | Same with built-in 2-port EtherNet/IP switch | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
