Siemens · Pressure Transmitters
SITRANS P320 Gauge Pressure Transmitter
Part number 7MF0340-1DM01-5AF2
Gauge pressure transmitter, 0–16 bar span, 0.065 % accuracy, 4–20 mA HART 7, SIL2/3, G1/2 process connection, 316L wetted parts.
- CE
- SIL2
- ATEX
- IECEx
- RoHS
- EAC
Overview
The SITRANS P320 is Siemens' current-generation process pressure transmitter, positioned between the compact P200 series and the high-performance P420. The code 7MF0340-1DM01-5AF2 specifies a gauge transmitter with 16 bar maximum span, G1/2B connection to EN 837-1, 316L wetted parts, HART 7 output and a backlit display. Three-button quick-start commissioning and remote safety activation through HART make it fast to deploy on utility and process pressure points; SIL2 (SIL3 redundant) covers safety loops.
Key features
- Reference accuracy 0.065 %, long-term drift < 0.09 % over 5 years
- HART 7 with remote safety commissioning; PROFINET and PROFIBUS PA variants
- SIL2 (SIL3 in redundant configuration) per IEC 61508
- Backlit display with three-button quick-start wizard
- ATEX / IECEx intrinsically safe and flameproof approvals
Typical applications
- Pump discharge and suction pressure
- Boiler and steam systems
- Filtration monitoring
- Pipeline and header pressure
Technical specifications — 7MF0340-1DM01-5AF2
| Process | |
|---|---|
| Measuring range | 0…16 bar gauge (span 1:100) |
| Process connection | G1/2B per EN 837-1 |
| Wetted parts | 316L stainless steel |
| Accuracy | |
| Reference accuracy | 0.065 % of span |
| Output | |
| Output | 4…20 mA / HART 7 |
| Safety | |
| Functional safety | SIL2 / SIL3 |
| Environment | |
| Ambient temperature | -40…+85 °C |
| Enclosure rating | IP66/68 |
Specifications are summarised from the manufacturer's documentation for selection purposes. Always confirm against the current datasheet before design-in; we send the datasheet and the exact ordering code with every quotation.
Related part numbers and alternatives
| Part number | Relationship | |
|---|---|---|
7MF0340-1DM21-5AF2 | Same transmitter with 1/2-14 NPT process connection | Quote |
7MF0340-1CM01-5AF2 | 4 bar span version | Quote |
7MF0440-1DM01-5AF2 | SITRANS P420 — 0.04 % accuracy, higher performance | Quote |
Not sure which variant you need? Send us the nameplate photo or the old part number and we will identify the current equivalent.
Supply, documentation and lead time
What you receive
- Genuine Siemens product in original packaging
- Commercial invoice and packing list; Certificate of Conformance on request
- Datasheet, declaration of conformity and country of origin as issued by the manufacturer
- Manufacturer warranty, period stated on the quotation
How we quote
- Reply within one business day with price, lead time and stock position
- Alternatives proposed when they improve price or delivery
- Incoterms of your choice: EXW Hai Phong, FOB/FCA, CIF/DAP to your site
- Consolidated shipments for multi-line orders; export documentation for buyers outside Vietnam
Indicative HS code 9026.20 — final classification is confirmed on the commercial invoice.
Frequently asked questions
Is the 7MF0340-1DM01-5AF2 available from stock, and what is the lead time?
Availability of the SITRANS P320 Gauge Pressure Transmitter changes with manufacturer production and distributor stock, so we confirm it per request rather than publishing a number that may be out of date. Send the part number and quantity through the quote form and you will receive stock position and lead time within one business day.
Is the 7MF0340-1DM01-5AF2 genuine, and what documentation comes with it?
We supply only genuine Siemens products sourced from the manufacturer or authorized distribution channels. Each delivery includes the commercial invoice and packing list; a Certificate of Conformance, declaration of conformity and country-of-origin statement are provided on request, and the manufacturer's warranty applies.
Can you ship the 7MF0340-1DM01-5AF2 outside Vietnam?
Yes. We quote EXW Hai Phong, FCA/FOB, CIF or DAP and prepare the export documentation. Buyers in Japan, ASEAN, Europe and North America regularly consolidate multi-brand orders with us into one shipment.
What if the 7MF0340-1DM01-5AF2 is the wrong variant for my application?
Tell us the application in the notes field. Our engineers check the ordering code against your supply voltage, I/O, communication and environmental requirements and propose the correct variant or a successor part before quoting — at no charge.
